DOWNLOAD YOUR SERVICE-REPAIR MANUALS HERE!
No Shipping Fees!
No Waiting for the Mail for a DVD or a BOOK to Come!
MITSUBISHI 4G1-ENGINE LANCER-COLT 1995-2010 SERVICE
Covers: 1995-2010 Lancer & Colt (engine only)
1990-96 Service Manual
MITSUBISHI ENGINE 4G63-4G64 1993 & UP SERVICE MANUAL (engine only)
Mitsubishi: Chariot, Galant, L200/Mighty Max, Dodge Ram 50, Eclipse, Pajero, RVR, Delica, Lancer Evolution, Hyundai Elantra, Sonata, Eagle Talon, Plymouth Laser, Proton Perdana, Delica/Van, L200, Mighty Max, Hyundai Grandeur, Mitsubishi Magna, Delica, Eclipse Spyder, Eclipse, Outlander, Triton, Chrysler Sebring/Dodge Stratus, Montero (V11 - 2 door) Latin America version
*Check the vehicle applications above before you order:
Manual for ENGINE-4G63-4G64 1993 & UP
MITSUBISHI ENGINE-4G63t 2.0L TURBO 1983-2006
1983-1998 Mitsubishi Chariot, 1988 Mitsubishi Cordia, 1988 Mitsubishi Tredia, 1989–2003 Mitsubishi Galant, 1987-199? Mitsubishi L200/Mighty Max, 1987-1989 Dodge Ram 50, 1990–1999 Mitsubishi Eclipse, 1993–1998 Mitsubishi Pajero, 1994–1998 Mitsubishi RVR, 1994–1998 Mitsubishi Delica, 1992–2006 Mitsubishi Lancer Evolution, 2001–2006 Mitsubishi Airtrek, 1987-1988 Hyundai Stellar, 1992-1995 Hyundai Elantra, 1989-2005 Hyundai Sonata, 2004–present Brilliance BS6, 1983–1992 Dodge Colt Vista, 1989-1992 Eagle Vista Wagon, 1990–1998 Eagle Talon, 1990–1994 Plymouth Laser, 1996–1999 Proton Perdana, 1993–1998 Mitsubishi Outlander.*Check the vehicle applications above before you order: Manual for ENGINE-4G63 2.0L TURBO
Engine Mechanical: 48 PAGES
4G63T Re-building: 68 PAGES
MITSUBISHI ENGINE 4G64 4G6-4G9 1986-2006 SERVICE MANUAL (engine only)
1987–1990 Mitsubishi Sapporo, 1988–1996 Mitsubishi Delica/Van, 1990–present Mitsubishi L200, 1990–1996 Mitsubishi Mighty Max, 1986-1998 Hyundai Grandeur, 1993-1997 Mitsubishi Chariot, 1994–2003 Mitsubishi Galant, 1996–1998 Mitsubishi Magna, 1994–2006 Mitsubishi Delica. 1996-1999 Mitsubishi Eclipse Spyder, 2000-2005 Mitsubishi Eclipse, 2003 Mitsubishi Outlander Mitsubishi Triton, 2005 Mitsubishi Zinger, 1989–1991 Hyundai Sonata, 1990–1992 Dodge Ram 50, 2001–2005 Chrysler Sebring/Dodge Stratus, 2004–present Brilliance BS6, 2008–present Chery V5, 2006–present Great Wall Hover, 1998-2005 Mitsubishi Montero (V11 - 2 door) Latin America version, 1983–1992 Dodge Colt Vista awd.
*Check the vehicle applications above before you order: Manual for ENGINE-4G64
MITSUBISHI ENGINE 4G6 1991-1992 1.6L-1.9L-2.0L-2.4L SERVICE MANUAL (engine only)
& 1992 only:
Mirage / Mitsubishi Colt (MPFI), Dodge Colt / Plymouth Colt, Eagle Summit, Hyundai Elantra, Chariot, Galant, Mitsubishi Eclipse, Mitsubishi Lancer Evolution, Hyundai Sonata, Dodge Colt Vista, Eagle Vista Wagon, Eagle Talon, Plymouth Laser, Mitsubishi Colt III, Mitsubishi Mirage, Mitsubishi Lancer, Mitsubishi Delica/Van, Mitsubishi L200, Mitsubishi Mighty Max, Hyundai Grandeur, Dodge Ram 50, Dodge Colt Vista awd.
*Check the vehicle applications above before you order: Manual for ENGINE-4G6 1991-1992
The SOHC 4G15 displaces 1.5 L (1468 cc) with a bore and stroke of 75.5 mm x 82.0mm. A version of the 4G15 was produced with gasoline multi port injection. It has approximately 92 hp (69 kW) on the 1993 Mirage model. A DOHC MIVEC turbo variant of the engine is also still in production to date (4G15T), serving in the Mitsubishi Colt series, offering 154 hp (115 kW) on the latest Colt Version-R (with exhaust enhancement).
- Mitsubishi Colt/Mirage
- Mitsubishi Lancer/Eagle Summit
- Mitsubishi Dingo
- Proton Saga/Iswara
- Proton Satria/Wira
MIVEC (Mitsubishi Innovative Valve timing Electronic Control system) is the brand name of a variable valve timing engine technology developed by Mitsubishi Motors. MIVEC, as with other similar systems, varies the timing, lift and duration of the valves by using two different camshaft profiles. At low speeds, a mild (low-lift) cam lobe provides stable idle, lower emissions and increased torque at lower speeds, while above a fixed engine speed a second set of cam lobes are activated, providing higher lift and duration; therefore a greater quantity of air into the combustion chamber which increases the power and torque output over a broad engine speed range.
MIVEC was first introduced in 1992 in their 4G92 powerplant, a 1,597 cc naturally aspirated DOHC 16 valve straight-4. At the time, the first generation of the system was named Mitsubishi Innovative Valve timing and lift Electronic Control. The first cars to use this were the Mitsubishi Mirage hatchback and the Mitsubishi Lancer sedan. While the conventional 4G92 engine provided 145 PS at 7000 rpm, the MIVEC-equipped engine could achieve 175 PS at 7500 rpm. Similar improvements were seen when the technology was applied to the 1994 Mitsubishi FTO, whose top-spec GPX variant had a 6A12 1997 cc DOHC 24 valve V6 with peak power of 200 PS at 7500 rpm. The GR model, whose otherwise identical powerplant was not MIVEC-equipped, produced 180 PS at 7000 rpm by comparison.
Although initially designed to enhance performance, the system has subsequently been developed to improve economy and emissions, and has been introduced across Mitsubishi's range of vehicles, from the i kei car to the high-performance Lancer Evolution sedan.
